1.2 M Width Serrated Swage-locked Steel Grating For Walkway Floor
Serrated Swage-locked Steel Grating Description:
Serrated Swage locked grating with lightweight and high load capacity, used as stair tread, floor, fence, ceiling, walkway, platform, screen, cover.
Common Steel Grating Specifications (In mm)
| Bearing bar pitch | Cross-bar pitch | Specification of bearing bar (width x thickness) |
| 20x3 | 25X3 | 32X3 | 40X3 | 20X5 | 25X5 |
| 30 | 100 | G203/30/100 | G253/30/100 | G323/30/100 | G403/30/100 | G205/30/100 | G255/30/100 |
| 50 | G203/30/50 | G253/30/50 | G323/30/50 | G403/30/50 | G205/30/50 | G255/30/50 |
| 40 | 100 | G203/40/100 | G253/40/100 | G323/40/100 | G403/40/100 | G205/40/100 | G255/40/100 |
| 50 | G203/40/50 | G253/40/50 | G323/40/50 | G403/40/50 | G205/40/50 | G255/40/50 |
| 60 | 50 | G203/60/50 | G253/60/50 | G253/60/50 | G403/60/50 | G205/60/50 | G255/60/50 |
| Bearing bar pitch | Cross-bar pitch | Specification of bearing bar (width x thickness) |
| 32x5 | 40x5 | 45x5 | 50x5 | 55X5 | 60X5 |
| 30 | 100 | G325/30/100 | G405/30/100 | G455/30/100 | G505/30/100 | G555/30/100 | G605/30/100 |
| 50 | G325/30/50 | G405/30/50 | G455/30/50 | G505/30/50 | G555/30/50 | G605/30/50 |
| 40 | 100 | G325/40/100 | G405/40/100 | G455/40/100 | G505/40/100 | G555/40/100 | G605/40/100 |
| 50 | G325/40/50 | G405/40/50 | G455/40/50 | G505/40/50 | G555/40/50 | G605/40/50 |
| 60 | 50 | G325/60/50 | G405/60/50 | G455/60/50 | G505/60/50 | G555/60/50 | G605/60/50 |
Serrated Swage-locked Steel Grating Features:
- 1. High strength, high bearing capacity and high resistance to stress.
- 2. Grating structure with the good drainage function, do not accumulate rain, snow, dust and debris.
- 3. Ventilation, lighting and heat dissipation.
- 4. Explosion protection, also can add anti-skid serrations to improve anti-skid ability.
- 5. Good ventilation and heat resistance.
- 6. Anti-corrosion, anti-rust, durable.
- 7. Simple and beautiful appearance.
- 8. Light weight, easy to install and remove.
- 9. Various styles and sizes for choice.
- 10. 100% recyclable.
Serrated Swage-locked Steel Grating Applications:
Steel gratings are widely used as stair tread, walkway, optional platform, catwalk stage, floor, showcase ground, ceiling, window, sun visor, fountain panel, ramp, lifting track, tree cover, trench cover, drainage cover, industrial truck, bridge construction, decorative wall, security fence, transformer reservoir, chair, shelve, stand, observation tower, baby carriage, substation fire pit, clean area panel, split obstacle or screen, food panel, etc.
